Heavy Duty Multi Blade Rip Saw Machine for Round Timber Log

Model No.

QHZY-180

Min Working Width

80mm

Max Working Width

180mm

Min Working Thickness

80mm

Max Working Thickness

170mm

Min Working Length

500mm

Max Working Length

Continuous Feed

Feeding Speed

Adjustable

Motor Power

18.5kwx2 set

Dimension

4000x1600x1300mm

Weight

1800kg

Model No.

QHZY-240

Min Working Width

100mm

Max Working Width

240mm

Min Working Thickness

100mm

Max Working Thickness

230mm

Min Working Length

700mm

Max Working Length

Continuous   Feed

Feeding Speed

Adjustable

Motor Power

30kwx2sets

Dimension

4200x1600x1600mm

Weight

2220kg

Key Features:

1.QHZY series log multi blade saw machines are suitable for sawing any kinds of log wood processing (diameter:150-400mm.length:more than 1000mm).This series take hold in long logs processing equipment because of designed and developed with technology innovation and basis on the original log multi blade saw machines.

2.Main shaft:made of high quality materials,chromium plated,dynamic balance processing,high stability,wear resisting rust.

3.Cooling system:shafts core spray techinology dustproof environmental protection,saw blades protection,extend the blades lives.

4.Case:the main box integration,stable performance,aging treatmentdurable.

5.Bearing:selecting the international well-know brands SKF,dust free heating assembly,high flexible degree of main shafts,extend the blades lives.

6.Blades:using high quality imported saw blades,heat resistant,wear resistant,deformation.

7.Feeding:automatic feeding.

8.Whole advantage:long woods processing,for any kinds of log wood sprocessing,convenient blades handling.

9.Efficiency:50-80cube/day.
