Home > Products > Plywood Press Section Machines > Plywood Assembly Machine

Plywood Forming Machine Veneer Assembly Machine Plywood Forming Line

Plywood Forming Machine Veneer Assembly Machine Plywood Forming LinePlywood Forming Machine Veneer Assembly Machine Plywood Forming LinePlywood Forming Machine Veneer Assembly Machine Plywood Forming Line
Product DETAILS

Technical Specification:

Model No.

BP1400 (4x8ft)

Assemble Size

1300x2600mm

Assemble Thickness

300mm

Worktable Length

30 meters

Cutting Method

Hydraulic Press Cutting

Feeding Speed

Speed Adjustable

Motor Power

11 kw

Dimension

40000x1800x2000 mm

Weight

4000kg



Model No.

BP1100 (3x6ft)

Assemble Size

1100x2100mm

Assemble Thickness

300mm

Worktable Length

30 meters

Cutting Method

Hydraulic Press Cutting

Feeding Speed

Speed Adjustable

Motor Power

7.4 kw

Dimension

38000x1500x2000mm

Weight

3500kg



Key Features:

1.Suitable for Assembly of Plywood Size 4x8ft and 3x6ft

2.Conveyor Length 30 meters or any other length you need,customized

3.Conveyor Speed adjustable according to your workers assemble speed

4.Automatic Sizing 1300x2600mm for 4x8ft,and 1100x2100mm for 3x6ft

5.Automatic Cutting at the Right Size

6.Automatic Stacking After Cutting

7.About 7 workers are required for a 30m conveyor

8.About 1000 sheets of plywood can be assembled within a shift 8 hours
